Google Meet Series One Room Kits from Lenovo

Turnkey room solutions for Google Meet

Lenovo and Google have partnered on a best-in-class series of Google Meet room kits. The Google Meet Series One room kits from Lenovo provide turnkey solutions for G Suite and Google Meet customers, tailored for three room sizes. Each box includes a size-appropriate combination of innovative, attractive hardware components to enable modern workplace collaboration.

Share this product

Description

Google Meet Series One Room Kits from Lenovo

Features

Outfit any space

Choose from three purpose-built options, depending on your need: small, medium, or large rooms. The Google Meet Series One room kits from Lenovo are comprehensive and ready out of the box. Each kit includes a compute system with custom mounting options, plus a combination of up to six other components—which vary by room size. Components include a smart camera or smart camera XL, a remote control or touch controller, up to two mic pods, and a smart audio bar (plus an add-on audio bar in the large room kit).

Modernize your meetings

These are the first room kits of their kind to carry the Series One designation, thanks to unique features like onboard-AI and enterprise-grade components. The innovative compute system features an exclusive tensor processing unit (TPU) that delivers top-of-the-line performance. TrueVoice™ noise cancellation technology scrubs audio to ensure ultra-clear communication. And the 4K-capable AI cameras deliver smoother pan/zoom movements.

Lenovo ThinkSmart Google Meet Room Kit with standard and large camera in charcoal

Easy to install and manage

As the first kits for Google Meet incorporating Power over Ethernet (PoE), Series One room kits are easier and more cost-effective to install than almost any other option. Here’s why: With power and network combined in one Ethernet cable, there are fewer cables to run and less clutter under or on the table. In addition, PoE installations can be completed faster than traditional deployments. And the kits are easily managed through the G Suite admin console, for seamless integration and control.

Lenovo ThinkSmart Google Meet Room Kit compute unit in charcoal

Approachable, reliable design

The approachable product design of the Series One room kits complements the modern workplace aesthetic. Its user-friendly interface makes it easy to join meetings and share content. The attractive components are available in two inviting colors: Chalk and Charcoal. The hardware is reliable and durable, backed by a three-year Lenovo Premier Support warranty—with extended coverage available at additional cost via Lenovo Smart Office Professional Services.

Lenovo ThinkSmart Google Meet Room Kit with two microphone pods in charcoal and chalk



Specifications may vary depending upon region / model.



  • Tech Specs

    Compute System:

    Mounting Options
    • Wall mount
    • Table stand
    Processor Intel® Core™ i7-8550U
    Memory 4GB RAM
    Storage 128GB SSD
    Wireless Data Network
    • WiFi (802.11AC) 2.4GHz / 5GHz
    • Bluetooth® 4.2 Ethernet (PoE)
    Ports
    • 2 x HDMI 1.4 output with CEC
    • HDMI 1.4 input video port
    • 5 x RJ45
    • 3 x USB Type-A
    • USB Type-C
    • Headphone / mic combo
    Dimensions (L x W x H) 135mm x 284mm x 29mm / 5.3″ x 11.2″ x 1.1″

    Smart Camera:

    • 12MP 1/2.3″ CMOS sensor
    • Up to 1080p @ 30 fps
    • f/2.8 aperture
    Optics
    • Ultrawide-angle glass optics
    • 120° horizontal field of view
    Connection RJ45 (PoE)
    Dimensions (L x W x H) 84mm x 107mm x 42mm / 3.3″ x 4.2″ x 1.7″

    Smart Camera XL (included in large kits only):

    • 20.3MP 1″ CMOS sensor
    • Up to 1080p @ 30 fps
    • f/2.9 aperture
    Optics
    • Wide-angle glass optics
    • 95° horizontal field of view
    Connection RJ45 (PoE)
    Dimensions (L x W x H) 84mm x 122mm x 52mm / 3.3″ x 4.8″ x 2″

    Smart Audio Bar:

    Speaker
    • 20W RMS power
    • 80Hz-24kHz frequency response
    Microphone
    • 8-element, linear beamforming array
    • 100Hz-24kHz pickup
    Audio Performance AEC, ANC, and TrueVoice™ multi-channel noise cancellation
    Connections
    • USB-C with USB 2.0 UAC
    • Stereo analog RCA output (for assistive listening devices)
    • RJ45 (PoE)
    • 2 x RJ45 (daisy chain output data and power)
    Range Optimal pickup range of up to 4m
    Dimensions (L x W x H) 95mm x 705mm x 133mm / 3.7″ x 27.75″ x 5.2″

    Add-on Audio Bar (included in large kits only):

    Speaker
    • 20W RMS power
    • 80Hz-24kHz frequency response
    Microphone
    • 8-element, linear beamforming array
    • 100Hz-24kHz pickup
    Range Optimal pickup range of up to 4m
    Dimensions (L x W x H) 95mm x 705mm x 133mm / 3.7″ x 27.75″ x 5.2″

    Mic Pod (included in medium and large kits only):

    Microphone
    • 8-element, circular beamforming array
    • 100Hz-24kHz pickup
    Connections
    • Daisy-chain input port for data and power (up to 4 mic pods)
    • Daisy-chain output port for data and power (up to 4 mic pods)
    Range Optimal pickup range of up to 2m
    Dimensions (L x W x H) 95mm x 95mm x 30mm / 3.7″ x 3.7″ x 1.2″

    Touch Controller (included in medium and large kits only):

    Display
    • 10.1″ anti-smudge touchscreen
    • Color sensor
    • Orientation sensor
    Resolution 1280 x 800 x 3 (RGB) LCD with optically bonded multi-touch screen
    Connection 10Gb PoE connector
    Dimensions (L x W x H) 164mm x 245mm x 91mm / 6.5″ x 9.6″ x 3.6″

    Remote Control (included in small kits only):

    Remote 2.4 RF remote
    Keypad
    • 10 keys (Navi Key, End Key, and Upper Keys)
    • QWERTY key: 38 keys
    Battery Rechargeable lithium ion with USB-powered docking station
    Dimensions (L x W x H) 130mm x 45mm x 14mm / 5.1″ x 1.8″ x 0.6″

    Specifications may vary depending upon region.

    Ports/Slots

    Compute System:

    Lenovo ThinkSmart Google Meet Room Compute rear view with ports labels
  • 1. Headphone / mic combo
  • 2. USB Type-C
  • 3. 3 x HDMI 1.4
  • 4. 3 x USB Type-A
  • 5. 5 x RJ45
  • 6. Kensington lock slot
  • 7. Power-in
  • Smart Audio Bar:

    Lenovo ThinkSmart Google Meet Room Speaker Bar rear view with ports labels
  • 1. Stereo analog RCA output
  • 2. USB-C with USB 2.0 UAC
  • 3. Power-in
  • 4. 2 x RJ45 (daisy-chain output data and power)
  • 5. RJ45 (PoE)
  • Smart Camera, Mic Pod, Touch Controller:

    Lenovo ThinkSmart Google Meet Room remote control, camera, microphone pad, and touch controller rear view with ports labels
  • 1. RJ45 (PoE)
  • 2. 10Gb PoE connector
  • 3. Daisy-chain input/output ports for data and power
